relay board circuit

Name: relay board circuit
Brand: N S ELECTRICALS
Price: 490.0 INR
Availability: InStock

Price 490.0 INR/ Piece

Get a Price/Quote

MOQ : 10 Pieces

relay board circuit Specification

Breaking Capacity
Up to 250V AC 10A

Mechanical Life
Up to 100,000 operations

Phase
Single Phase

Product Type
Relay Board Circuit

Installation Options
PCB mounting, screw terminals

Function
Switching electrical loads remotely

Poles Number
1 Pole

Rated Voltage
5V DC (coil)

Rated Current
10A per channel

Rated Frequency
50/60Hz

Temperature Protection
No inbuilt temperature protection

Weight
Approx. 120g

Color
Blue PCB

Dimensions
Approximately 75mm x 55mm x 18mm

LED Indicators
Status indication for each relay

Operating Temperature Range
-20C to +70C

Input Control Voltage
3.3V to 5V

Trigger Level
Active Low

Number of Relays
4 channels

PCB Material
FR-4

Isolation
Opto-isolated inputs

Contact Type
SPDT (Single Pole Double Throw)

Output Connections
Screw terminals (NO, NC, and COM)

Mounting Holes
Provided for panel mounting

relay board circuit Trade Information

Minimum Order Quantity
10 Pieces

Supply Ability
1000 Pieces Per Month

Delivery Time
7 Days

About relay board circuit

Experience a marvelous instant checkout with our opulent 4-channel relay board circuit-perfect for retailers, suppliers, traders, and wholesalers across India. Crafted from world-class FR-4 material, this featured relay board boasts active-low opto-isolated inputs and SPDT contact type, ensuring secure and reliable switching. Save both time and resources as you remotely manage diverse electrical loads up to 250V AC 10A. LED indicators, screw terminals, and robust mounting options make installation hassle-free. Enjoy remarkable savings, outstanding durability, and high-grade performance in every operation.

Versatile Applications & Superior Material

This relay board circuit, crafted from premium FR-4 material, is designed for seamless switching in industrial automation, home appliances, motor control, and DIY projects. Its opto-isolated inputs ensure safety, while LED indicators offer at-a-glance status updates. The board's opulent build quality, spacious panel mounting holes, and blue PCB make it both functional and visually appealing. Featuring 4 channels, it is ideal for environments demanding reliable, world-class switching and control solutions.

Packaging, Delivery & Order Fulfillment

Relay board circuits are carefully packed in anti-static, shock-proof packaging to ensure safe drop-off and delivery. Shipped goods are dispatched via trusted carriers, and we provide FOB Port services as per client preference. Retailers and traders can request exchange samples, allowing hands-on evaluation before making a bulk purchase. Our quick shipping process ensures minimal waiting time, facilitating a seamless buying experience and product satisfaction from order to installation.
